Disassemble the DS Lite
- Use a knife to pry off the two rubber feet (there are screws underneath).
- Lift the back half of the case off of the DS.
- Remove the remaining screw that is holding the PCB in place.
- Disconnect the black antenna wire from the WiFi module and pull it out from under the Slot-1 assembly.
How do you take off a 3DS case?
Hold the device in one hand and turn it over. Grab the top edge of the back cover with your opposite hand so that the cover does not fall back into place. Flip the 3DS over again so that the back cover is facing up. Pull the back cover up and away from the rest of the device to remove it.
How do you clean a Nintendo DS Lite?
To clean a dirty screen:
- Slightly dampen a corner of the cloth with water and wipe off the screens to loosen any dirt or foreign material.
- Using a dry portion of the same cloth, wipe the screens to dry them and finish the cleaning process.
- If needed repeat the process more than once.
Does the new 3DS XL have cover plates?
On the New Nintendo 3DS only the front cover plate is removable. On the New Nintendo 3DS XL only the back cover plate is removable. Do not attempt to remove the cover plates with anything other than the recommended type and size of screwdriver.
How do you remove the front cover of a new 3DS XL?
For the front cover plate Use the nub on the end of the stylus to gently pry on the small slots on each side near the L and R buttons. Once the cover plate begins to separate from the system, gently remove it.
How long does a new 3DS XL battery last?
How Long Will the Battery Remain Charged?
| System | Using Nintendo 3DS software | Using Nintendo DS software |
|---|---|---|
| Nintendo 3DS XL | 3.5 – 5.5 hours | 6 – 10 hours |
| Nintendo 2DS | 3.5 – 5.5 hours | 5 – 9 hours |
| New Nintendo 3DS | 3.5 – 6 hours | 6.5 – 10.5 hours |
| New Nintendo 3DS XL | 3.5 – 7 hours | 7 – 12 hours |
